09:00 h - 17:00 h (Tuesday and Wednesday)


Module 1 - Basics in light engineering

•    Colour temperature
•    Colour rendering index
•    Temperature increase
•    Depth of illumination
•    Luminous efficiency
•    Modelling (small/large light field)
•    Depth illumination
•    Depth modelling
•    Measuring technique illumination (Lux)
•    Procedure for vigilance cases

Module 2 - Installation of the "sub - construction / heavy duty anchors"

•    Legal aspects
•    Overview
•    Different surfaces
•    Correct preparation
•    Torque test
•    Axial and edge distance
•    Heavy-duty anchors (HST)
•    Ten golden rules

Module 3 - OR - light installation

•    Requirements (real and false ceiling, supply voltage, wiring etc.)
•    Certificate of static load capacity of ceiling
•    Commissioning


Module 4 - measuring techniques (DIN EN 60601-1 / DIN EN 60601-2-2 / DIN EN 62353)

•    Inspection

Module 6 - schematics of the OR-lights / marLED®V

•    KLS Martin marLED®V10 / V16
•    Troubleshooting and exchange of complete printed circuit boards
•    Software update
•    Maintenance, adjusting, measuring technique


Module 7 - Schematics of the OR-lights / marLED®E

•    KLS marLED®E3, E9, E9i and E15
•    KLS marLED®E – Battery

• Troubleshooting and exchange of complete printed circuit boards
• Software update

Module 8 -Schematics of the OR-Lights / marLED^®X

•    KLS marLED®X

• Troubleshooting and exchange of complete printed circuit boards
• Software update
• Maintenance, adjusting, measuring technique

Module 9 - Schematics of the OR-lights / video system

• KLSMartin flat screen monitor system TFT FS / TFT marView
• KLS Martin surgiCam SD & HD & 4 K
• Scale OR
• Conduct OR
• S – Video amplifier
• Troubleshooting and exchange of complete printed circuit boards
• Maintenance, adjusting, measuring technique

Module 11 - Replacing "old ML / marLUX^®-Light / marLED®V-Lights“with new marLED^®E and marLED^®X-Lights

• Checklist for the modification
• Excel configurator
• Commissioning

Module 1 - Basics in gas supply

•    Requirements gas supply
•    Diameter of the gas tubing
•    Gas – interface with NIST – connection
•    Gas – interface without NIST – connection
•    Gas interfaces with and without check – valve
•    AGSS with Venturi
•    AGSS with a pump system requirements surgical pendant
•    Requirements anaesthesia pendant
             o    Gas norms:
             o    British norm (HTM 2022) with NIST – connection
             o    EN 737 / 11197
             o    Colour coded hoses
•    Gas media check

Module 3 - Pendant Installation

•    Mounting the:
           o    Intermediate ceiling construction
           o    Interface plate
           o    Boom arm / single / double
           o    Service head
•    Adjustment works / setting:
           o    Stop screws at each joint
           o    Mechanical brake screws
           o    Vertical lift on the motor arm
           o    Correction of the vertical alignment

Module 4 - Measuring techniques (DIN EN 60601-1 / DIN EN 60601-2-2 / DIN EN 62353)

•    Commissioning
•    Inspection
•    Gas – media check

Module 5 - Troubleshooting & maintenance

•    Replacing components

09:00 h - 17:00 h (Thursday)
09:00 h - 15:00 h (Friday)


Module 1 - Basic in electro surgery

•    Terminology
•    Application and risk
•    Commissioning
•    Procedure for vigilance cases


Module 2 - Product training

•    Application & hands on
•    Maxium programming
•    marClamp ® / marClamp ® IQ / marSeal / marTest

Module 3 - HF measuring techniques (DIN EN 60601-1 / DIN EN 60601-2-2 / DIN EN 62353)

•    Safety check acc. to the MDR
•    Calibration

Measuring devices:

•    HF-electro surgical power meter
•    Safety tester
•    Measuring adapter
•    HF-power
•    HF-leakage current
•    Safety control
•    Isolation – and protection earth measurement
•    Earth – enclosure – patient – leakage current
•    Auxiliary current

Module 4 - Schematic / exchange, calibration and troubleshooting

 maXium®
•    Software update
•    maXium PC
•    Creating service reports

maXium® smart C
•    Software update
•    Advanced fini tests
•    Maintenance
•    Enter serial number
•    Read out and transfer device settings

MD 62 / Mini Cutter / ME 102
ME MB 1 Endo / ME M 1 / ME MB2 / ME MB 3

1. The training concerns only electromedical products.

Target groups:

Technicians and service engineers of our distributors and service partners

2. Registration for each module has to be done at least 2 weeks before the training starts.

3. The number of participants shall be at least 5 and shall not exceed 12 participants.

4. Each participant will obtain a certificate.


Please note:
A test will be performed after each training unit.
